Single End Chamfering/Deburring of Tube, Pipe, & Solid Bar
Soco EF-AC/603/4" to 2.25" OD
Soco EF-AC/801" to 3.25" OD
Soco EF-AC/1151.5" to 5" OD
Soco Single End Chamfering/Deburring Machines provide the most economical, efficient and low operating cost for end finishing/deburring of tube, pipe, & solid bar. New machine models come standard with fully enclosed cabinet for operator safety, inverter variable speed, semi auto operation clamping, chamfering, & releasing of material. Chamfering/Deburring of OD, ID, & Face are performed Simultaneously.
Soco Double End Chamfering Machines(Long Lengths Series)
Soco DEF-FA/52Double End Tube/Pipe Chamfering for Working Lengths from150mm(5.906") - 1000mm(39.37") Standard150mm(5.906") -2000mm(78.74") Optional Capacity up to 52mm(2.047") OD.Fully Automatic Loading, Feeding, & Chamfering
Soco DEF-FA/76VDouble End Chamfering with Long Working Lengths From200mm(7.874") - 1000mm(39.37") Standard200mm(7.874") - 3000mm(118.11") OptionalCapacity up to 76mm(2.992") OD.Automatic Loading, Feeding and Chamfering.May be connected to Soco SA-78NCE Automatic Saw forAutomation Cells.
Soco FM-76VDouble End Automatic Tube Chamfering + Length Measuringit is possible to simultaneously chamfer both end of tube andmeasure their lengths with tolerances as low as +/- 0.02mmUsing as absolute length measuring system (against a calibrated piece), The machines may also be programmed to stop after a certain number of pieces do not fall withing the specified length tolerance. Fully Automatic loading, feeding, chamfering and length measuring.200mm(7.874") - 1000mm(39.37") Standard250mm(9.843") - 3000mm(118.11") OptionalCapacity up to 76mm(2.992") OD.
Soco Double End Chamfering Machines(Short Lengths Series)
Ideal for chamfering short working lengths 25mm(0.984") - 300mm(11.811"). With an optional BTM, the machines offer a completely automatic loading, feeding and chamfering process. This range is suitable for clean and even chamfer of both ends of tube, as well as radius (round) chamfering and / or chamfering the inside + outside and face of the material. It may also be used for outside chamfering of solid bars.
Soco DEF-FA/60SSFully Automatic Chamfering System for Short Work Lengths25mm(0.984") - 300mm(11.811")Working Capacity12mm(0.472") - 60mm(2.362") OD.
Soco DEF-FA/85SSFully Auto Double End Chamfering Machine for Short Lengths25mm(0.984") - 300mm(11.811")Working Capacity25mm(0.984") - 85mm(3.346") OD.
Soco DEF-FANC/127SSNC Touch Screen Control for Automatic Double End Chamfering.Servo Control Cutting Head & Feeding for Short Lengths.25mm(0.094") - 250mm(9.843")Working Capacity60mm(2.362") - 127mm(5") OD.
Soco Chamfering Machines Info/Request Form
