Trennjaeger VCT 370 DG
Fully Automatic CNC Mitering Cold Saw
Trennjaeger VCT 370 DG Fully Automatic CNC Miter Cold Saw:
Cutting Area 90 Degree +/-45 Degrees (60 Degree Optional)
Round Material: 3.543" @ 90* - 3.15" @ 45*
Rectangle: 3.937" x 3.15" @ 90* - 3.937" x 1.772" @ 45*
Square: 3.543" x 3.543" @ 90* - 3.15" x 3.15" @ 45*
High performance gearbox, heavy duty worm gear drive.
- 350/370mm diameter HSS metal circular cold saw blades
- Fully automatic CNC sawing +/-45* (60* optional)
- Sawhead feed via ball screw and servo drive
- Material feed via ball screw and servo drive
- Touch Screen control 200 programs, 10 different cut lengths per bar
- +/-.007" Cutting length accuracy
- Speed frequency controlled from 20 to 80m/min.
- Adjustable cut depth & height, variable sawhead feed
- Mist & Flood Coolant
- Hydraulic unit
Trennjaeger Automatic Mitering Cold Saw
Model LTS 520 Automatic CNC
Automatic Mitering Cold Saw Machine Model LTS 520 Automatic Pusher.
- 19.685' Automatic Pusher System
- Linear or Horizontal Blade Feed
- Hydraulic Operation
- German Made
- 550mm HSS Circular Cold Saw Blade
- CNC Miter Cutting 90-45-30 Degrees left or right
- Variable Blade Speed
Cutting Capacity: 550mm (21-/12") 90 Degrees 45 Degrees 30 Degrees
Round Tubing 7" 7" 6-1/2"
Square 13" x 7" 9" x 7" 7-3/4" x 6-1/2"
Rectangular 15-3/4" x 6-1/2 11-3/4" x 6" 7-3/4" x 6-1/2"
